★★★raspbian で　ルートを　USBハードディスクにする

すべてハードディスクで運用
です、　youtubeにも載ってますね

これは　前のraspbianではできたのですが、
stretchでは　何故か失敗。

従って　以下のでは上の図の如く

rootを　USBハードディスクにおいた。
micro SD はセルモーターのように起動に必要なだけとなった。

このUSBドライブは　容量が３２0Gあるので　raspberry pi 3は　立派なサーバーとなった。

たくさん書かれてますが、　rsync を利用した方法でやってみました。
https://www.raspberrypi.org/documentati ... des/msd.md
ここが出発点ですが　ちょっと不親切です。

1) raspbian を普通に　マイクロsd　で立ち上げます。

2) rewrite /boot/config.txt
dtoverlay=hifiberry-dacplus
dtparam=audio=on
program_usb_boot_mode=1

3) 再び　raspbian を普通に　マイクロsd　でたちあげ
そして次を確かめます
vcgencmd otp_dump | grep 17:

が
# > 17:3020000a
こうなってなうといけません
( たしかにこうなってたが　stretch では何かがかわったのか
　USB　HDDのみの運用は　結果的にはだめで
スターターとしての　マイクロSDカードが要った　）　

4)この後　 raspbian　をシャットダウンし　マイクロsdを抜き取ります。

-------------------------

5) 以下　 archlinuxの PC　に
マイクロSDカードと　USBハードディスクをつけます

まず　raspbian のマイクロSD（/dev/sdc）のブートローダ部分を
HDD（/dev/sdd）に　コピーするため

dd if=/dev/sdc of=/dev/sdd bs=512 count=16000
します

6)いま
マイクロsd は　以下です
fdisk -l /dev/sdc
Disk /dev/sdc: 15 GiB, 16088301568 bytes, 31422464 sectors
Device Boot Start End Sectors Size Id Type
/dev/sdc1 8192 93596 85405 41.7M c W95 FAT32 (LBA)
/dev/sdc2 94208 27277311 27183104 13G 83 Linux

さて　USB ハードディスクをを次のようにします。
1 8192 1056767 512.0 MiB 0700 Microsoft basic data
2 5252000 125542366 57.4 GiB 8300 Linux filesystem
3 1056800 5251071 2.0 GiB 8200 Linux swap

mkfs.vfat /dev/sdd1
mkfs.ext4 /dev/sdd2
mkswap /dev/sdd3

6)
mount /dev/sdc1 /mc1
mount /dev/sdc2 /mc2

mount /dev/sdd1 /md1
mount /dev/sdd2 /md2

rsync -avHx /mc1/ /md1/
rsync -avHx /mc2/ /md2/

別法

(cd /mc2;tar cvpf - . ) | (cd /md2 ; tar xpf - )

7)ファイルを３つ書き換えます
cp /md1/cmdline.txt /md1/cmdline.txt-ori
/md1/cmdline.txt
dwc_otg.lpm_enable=0 console=serial0,115200 console=tty1 root=/dev/sda2 rootfstype=ext4 elevator=deadline fsck.repair=yes rootwait quiet splash plymouth.ignore-serial-consoles

/md2/etc/fstab
proc /proc proc defaults 0 0
/dev/sda1 /boot vfat defaults 0 2
/dev/sda2 / ext4 defaults,noatime 0 1
/dev/sda2 none swap defaults 0 0

/md2/etc/rc.local
_IP=$(hostname -I) || true
if [ "$_IP" ]; then
printf "My IP address is %s\n" "$_IP"
fi
sleep 30
service dphys-swapfile stop
exit 0

8) umount /md1 /md2 /mc1 /mc2

9)こうしておいてから　USBハードディスクだけをRpi3にくっつけて電源をいれると
たちあがります。

PS)
なお　元のSDのみの運用に戻す時は
cp /md1/cmdline.txt-ori　 /md1/cmdline.txt
です

以下は現在の状態です

/etc/rc.local

_IP=$(hostname -I) || true
if [ "$_IP" ]; then
printf "My IP address is %s\n" "$_IP"
fi
sleep 30
service dphys-swapfile stop
/home/pi/sshd+swapon.bat
exit 0

/home/pi/sshd+swapon.bat
swapon /dev/sda3
/etc/init.d/ssh restart

/etc/fstab
proc /proc proc defaults 0 0
/dev/sda1 /boot vfat defaults 0 2
/dev/sda2 / ext4 defaults,noatime 0 1
/dev/sda2 none swap defaults 0 0

/boot/config.txt
dtoverlay=hifiberry-dacplus
dtparam=audio=on

/boot/cmdline.txt
dwc_otg.lpm_enable=0 console=serial0,115200 console=tty1 root=/dev/sda2 rootfstype=ext4 elevator=deadline fsck.repair=yes rootwait quiet splash plymouth.ignore-serial-consoles

/etc/rc.local

_IP=$(hostname -I) || true

if [ "$_IP" ]; then

printf "My IP address is %s\n" "$_IP"

sleep 30

service dphys-swapfile stop

exit 0

ファイルシス 1K-ブロック使用使用可使用% マウント位置

/dev/root 295746776 5530632 275123332 2% /

devtmpfs 470116 0 470116 0% /dev

tmpfs 474724 0 474724 0% /dev/shm

tmpfs 474724 12372 462352 3% /run

tmpfs 5120 4 5116 1% /run/lock

tmpfs 474724 0 474724 0% /sys/fs/cgroup

/dev/sda1 523992 23064 500928 5% /boot

tmpfs 94944 0 94944 0% /run/user/1000

/dev/mmcblk0p1 42131 22141 19990 53% /media/pi/boot

free

total used free shared buff/cache available

Mem: 949452 99728 518196 12668 331528 772580

Swap: 10485592 0 10485592

ifconfig
eth0: flags=4099<UP,BROADCAST,MULTICAST> mtu 1500
ether b8:27:eb:ce:cf:d8 txqueuelen 1000 (イーサネット)
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0

lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536
inet 127.0.0.1 netmask 255.0.0.0
inet6 ::1 prefixlen 128 scopeid 0x10<host>
loop txqueuelen 1000 (ローカルループバック)
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0

wlan0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500
inet 192.168.122.8 netmask 255.255.255.0 broadcast 192.168.122.255
inet6 fe80::8836:20cd:a2f0:85d5 prefixlen 64 scopeid 0x20<link>
ether b8:27:eb:9b:9a:8d txqueuelen 1000 (イーサネット)
RX packets 525 bytes 56580 (55.2 KiB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 267 bytes 39811 (38.8 KiB)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0

iptables -L
Chain INPUT (policy ACCEPT)
target prot opt source destination

Chain FORWARD (policy ACCEPT)
target prot opt source destination

Chain OUTPUT (policy ACCEPT)
target prot opt source destination

# dmesg
root@raspberrypi:/home/pi# ./comment-out.bat d0
[ 0.000000] Booting Linux on physical CPU 0x0
[ 0.000000] Linux version 4.14.34-v7+ (dc4@dc4-XPS13-9333) (gcc version 4.9.3 (crosstool-NG crosstool-ng-1.22.0-88-g8460611)) #1110 SMP Mon Apr 16 15:18:51 BST 2018
[ 0.000000] CPU: ARMv7 Processor [410fd034] revision 4 (ARMv7), cr=10c5383d
[ 0.000000] CPU: div instructions available: patching division code
[ 0.000000] CPU: PIPT / VIPT nonaliasing data cache, VIPT aliasing instruction cache
[ 0.000000] OF: fdt: Machine model: Raspberry Pi 3 Model B Rev 1.2
[ 0.000000] Memory policy: Data cache writealloc
[ 0.000000] cma: Reserved 8 MiB at 0x3ac00000
[ 0.000000] On node 0 totalpages: 242688
[ 0.000000] free_area_init_node: node 0, pgdat 80c84e40, node_mem_map ba3a1000
[ 0.000000] Normal zone: 2133 pages used for memmap
[ 0.000000] Normal zone: 0 pages reserved
[ 0.000000] Normal zone: 242688 pages, LIFO batch:31
[ 0.000000] random: fast init done
[ 0.000000] percpu: Embedded 17 pages/cpu @ba34a000 s38720 r8192 d22720 u69632
[ 0.000000] pcpu-alloc: s38720 r8192 d22720 u69632 alloc=17*4096
[ 0.000000] pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
[ 0.000000] Built 1 zonelists, mobility grouping on. Total pages: 240555
[ 0.000000] Kernel command line: 8250.nr_uarts=0 bcm2708_fb.fbwidth=1184 bcm2708_fb.fbheight=624 bcm2708_fb.fbswap=1 vc_mem.mem_base=0x3ec00000 vc_mem.mem_size=0x40000000 dwc_otg.lpm_enable=0 console=ttyS0,115200 console=tty1 root=/dev/sda2 rootfstype=ext4 elevator=deadline fsck.repair=yes rootwait quiet splash plymouth.ignore-serial-consoles
[ 0.000000] PID hash table entries: 4096 (order: 2, 16384 bytes)
[ 0.000000] Dentry cache hash table entries: 131072 (order: 7, 524288 bytes)
[ 0.000000] Inode-cache hash table entries: 65536 (order: 6, 262144 bytes)
[ 0.000000] Memory: 940236K/970752K available (7168K kernel code, 575K rwdata, 2072K rodata, 1024K init, 706K bss, 22324K reserved, 8192K cma-reserved)
[ 0.000000] Virtual kernel memory layout:
vector : 0xffff0000 - 0xffff1000 ( 4 kB)
fixmap : 0xffc00000 - 0xfff00000 (3072 kB)
vmalloc : 0xbb800000 - 0xff800000 (1088 MB)
lowmem : 0x80000000 - 0xbb400000 ( 948 MB)
modules : 0x7f000000 - 0x80000000 ( 16 MB)
.text : 0x80008000 - 0x80800000 (8160 kB)
.init : 0x80b00000 - 0x80c00000 (1024 kB)
.data : 0x80c00000 - 0x80c8fd4c ( 576 kB)
.bss : 0x80c96f4c - 0x80d478b4 ( 707 kB)
[ 0.000000] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=4, Nodes=1
[ 0.000000] ftrace: allocating 25231 entries in 74 pages
[ 0.000000] Hierarchical RCU implementation.
[ 0.000000] NR_IRQS: 16, nr_irqs: 16, preallocated irqs: 16
[ 0.000000] arch_timer: cp15 timer(s) running at 19.20MHz (phys).
[ 0.000000] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x46d987e47, max_idle_ns: 440795202767 ns
[ 0.000007] sched_clock: 56 bits at 19MHz, resolution 52ns, wraps every 4398046511078ns
[ 0.000019] Switching to timer-based delay loop, resolution 52ns
[ 0.000267] Console: colour dummy device 80x30
[ 0.000285] console [tty1] enabled
[ 0.000310] Calibrating delay loop (skipped), value calculated using timer frequency.. 38.40 BogoMIPS (lpj=192000)
[ 0.000325] pid_max: default: 32768 minimum: 301
[ 0.000642] Mount-cache hash table entries: 2048 (order: 1, 8192 bytes)
[ 0.000657] Mountpoint-cache hash table entries: 2048 (order: 1, 8192 bytes)
[ 0.001590] Disabling memory control group subsystem
[ 0.001670] CPU: Testing write buffer coherency: ok
[ 0.002066] CPU0: thread -1, cpu 0, socket 0, mpidr 80000000
[ 0.002444] Setting up static identity map for 0x100000 - 0x10003c
[ 0.002561] Hierarchical SRCU implementation.
[ 0.003190] smp: Bringing up secondary CPUs ...
[ 0.003876] CPU1: thread -1, cpu 1, socket 0, mpidr 80000001
[ 0.004627] CPU2: thread -1, cpu 2, socket 0, mpidr 80000002
[ 0.005358] CPU3: thread -1, cpu 3, socket 0, mpidr 80000003
[ 0.005463] smp: Brought up 1 node, 4 CPUs
[ 0.005473] SMP: Total of 4 processors activated (153.60 BogoMIPS).
[ 0.005479] CPU: All CPU(s) started in HYP mode.
[ 0.005483] CPU: Virtualization extensions available.
[ 0.006336] devtmpfs: initialized
[ 0.017081] VFP support v0.3: implementor 41 architecture 3 part 40 variant 3 rev 4
[ 0.017300] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
[ 0.017319] futex hash table entries: 1024 (order: 4, 65536 bytes)
[ 0.017876] pinctrl core: initialized pinctrl subsystem
[ 0.018609] NET: Registered protocol family 16
[ 0.021329] DMA: preallocated 1024 KiB pool for atomic coherent allocations
[ 0.026132] hw-breakpoint: found 5 (+1 reserved) breakpoint and 4 watchpoint registers.
[ 0.026139] hw-breakpoint: maximum watchpoint size is 8 bytes.
[ 0.026349] Serial: AMBA PL011 UART driver
[ 0.027970] bcm2835-mbox 3f00b880.mailbox: mailbox enabled
[ 0.028429] uart-pl011 3f201000.serial: could not find pctldev for node /soc/gpio@7e200000/uart0_pins, deferring probe
[ 0.059975] bcm2835-dma 3f007000.dma: DMA legacy API manager at bb813000, dmachans=0x1
[ 0.061482] SCSI subsystem initialized
[ 0.061704] usbcore: registered new interface driver usbfs
[ 0.061756] usbcore: registered new interface driver hub
[ 0.061841] usbcore: registered new device driver usb
[ 0.070087] raspberrypi-firmware soc:firmware: Attached to firmware from 2018-04-16 18:16
[ 0.071503] clocksource: Switched to clocksource arch_sys_counter
[ 0.148894] VFS: Disk quotas dquot_6.6.0
[ 0.148979] VFS: Dquot-cache hash table entries: 1024 (order 0, 4096 bytes)
[ 0.149164] FS-Cache: Loaded
[ 0.149362] CacheFiles: Loaded
[ 0.158172] NET: Registered protocol family 2
[ 0.158893] TCP established hash table entries: 8192 (order: 3, 32768 bytes)
[ 0.159003] TCP bind hash table entries: 8192 (order: 4, 65536 bytes)
[ 0.159189] TCP: Hash tables configured (established 8192 bind 8192)
[ 0.159319] UDP hash table entries: 512 (order: 2, 16384 bytes)
[ 0.159363] UDP-Lite hash table entries: 512 (order: 2, 16384 bytes)
[ 0.159591] NET: Registered protocol family 1
[ 0.160034] RPC: Registered named UNIX socket transport module.
[ 0.160040] RPC: Registered udp transport module.
[ 0.160045] RPC: Registered tcp transport module.
[ 0.160050] RPC: Registered tcp NFSv4.1 backchannel transport module.
[ 0.161675] hw perfevents: enabled with armv7_cortex_a7 PMU driver, 7 counters available
[ 0.164423] workingset: timestamp_bits=14 max_order=18 bucket_order=4
[ 0.172329] FS-Cache: Netfs 'nfs' registered for caching
[ 0.172914] NFS: Registering the id_resolver key type
[ 0.172949] Key type id_resolver registered
[ 0.172955] Key type id_legacy registered
[ 0.172970] nfs4filelayout_init: NFSv4 File Layout Driver Registering...
[ 0.174831] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 251)
[ 0.174952] io scheduler noop registered
[ 0.174959] io scheduler deadline registered (default)
[ 0.175235] io scheduler cfq registered
[ 0.175242] io scheduler mq-deadline registered
[ 0.175248] io scheduler kyber registered
[ 0.177952] BCM2708FB: allocated DMA memory fad10000
[ 0.177979] BCM2708FB: allocated DMA channel 0 @ bb813000
[ 0.199092] Console: switching to colour frame buffer device 148x39
[ 0.212329] bcm2835-rng 3f104000.rng: hwrng registered
[ 0.212470] vc-mem: phys_addr:0x00000000 mem_base=0x3ec00000 mem_size:0x40000000(1024 MiB)
[ 0.212941] vc-sm: Videocore shared memory driver
[ 0.213215] gpiomem-bcm2835 3f200000.gpiomem: Initialised: Registers at 0x3f200000
[ 0.222799] brd: module loaded
[ 0.231443] loop: module loaded
[ 0.231457] Loading iSCSI transport class v2.0-870.
[ 0.232140] libphy: Fixed MDIO Bus: probed
[ 0.232232] usbcore: registered new interface driver lan78xx
[ 0.232286] usbcore: registered new interface driver smsc95xx
[ 0.232303] dwc_otg: version 3.00a 10-AUG-2012 (platform bus)
[ 0.460419] Core Release: 2.80a
[ 0.460428] Setting default values for core params
[ 0.460461] Finished setting default values for core params
[ 0.660702] Using Buffer DMA mode
[ 0.660708] Periodic Transfer Interrupt Enhancement - disabled
[ 0.660713] Multiprocessor Interrupt Enhancement - disabled
[ 0.660721] OTG VER PARAM: 0, OTG VER FLAG: 0
[ 0.660731] Dedicated Tx FIFOs mode
[ 0.661103] WARN::dwc_otg_hcd_init:1046: FIQ DMA bounce buffers: virt = 0xbad04000 dma = 0xfad04000 len=9024
[ 0.661128] FIQ FSM acceleration enabled for :
Non-periodic Split Transactions
Periodic Split Transactions
High-Speed Isochronous Endpoints
Interrupt/Control Split Transaction hack enabled
[ 0.661135] dwc_otg: Microframe scheduler enabled
[ 0.661190] WARN::hcd_init_fiq:459: FIQ on core 1 at 0x805e6a40
[ 0.661201] WARN::hcd_init_fiq:460: FIQ ASM at 0x805e6da8 length 36
[ 0.661213] WARN::hcd_init_fiq:486: MPHI regs_base at 0xbb87e000
[ 0.661269] dwc_otg 3f980000.usb: DWC OTG Controller
[ 0.661302] dwc_otg 3f980000.usb: new USB bus registered, assigned bus number 1
[ 0.661333] dwc_otg 3f980000.usb: irq 62, io mem 0x00000000
[ 0.661380] Init: Port Power? op_state=1
[ 0.661385] Init: Power Port (0)
[ 0.661610] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002
[ 0.661621] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[ 0.661630] usb usb1: Product: DWC OTG Controller
[ 0.661638] usb usb1: Manufacturer: Linux 4.14.34-v7+ dwc_otg_hcd
[ 0.661646] usb usb1: SerialNumber: 3f980000.usb
[ 0.662241] hub 1-0:1.0: USB hub found
[ 0.662280] hub 1-0:1.0: 1 port detected
[ 0.662820] dwc_otg: FIQ enabled
[ 0.662825] dwc_otg: NAK holdoff enabled
[ 0.662830] dwc_otg: FIQ split-transaction FSM enabled
[ 0.662839] Module dwc_common_port init
[ 0.663068] usbcore: registered new interface driver usb-storage
[ 0.663230] mousedev: PS/2 mouse device common for all mice
[ 0.663300] IR NEC protocol handler initialized
[ 0.663305] IR RC5(x/sz) protocol handler initialized
[ 0.663310] IR RC6 protocol handler initialized
[ 0.663315] IR JVC protocol handler initialized
[ 0.663321] IR Sony protocol handler initialized
[ 0.663326] IR SANYO protocol handler initialized
[ 0.663331] IR Sharp protocol handler initialized
[ 0.663336] IR MCE Keyboard/mouse protocol handler initialized
[ 0.663341] IR XMP protocol handler initialized
[ 0.664022] bcm2835-wdt 3f100000.watchdog: Broadcom BCM2835 watchdog timer
[ 0.664288] bcm2835-cpufreq: min=600000 max=1200000
[ 0.664649] sdhci: Secure Digital Host Controller Interface driver
[ 0.664653] sdhci: Copyright(c) Pierre Ossman
[ 0.665002] mmc-bcm2835 3f300000.mmc: could not get clk, deferring probe
[ 0.665325] sdhost-bcm2835 3f202000.mmc: could not get clk, deferring probe
[ 0.665423] sdhci-pltfm: SDHCI platform and OF driver helper
[ 0.666817] ledtrig-cpu: registered to indicate activity on CPUs
[ 0.666989] hidraw: raw HID events driver (C) Jiri Kosina
[ 0.667101] usbcore: registered new interface driver usbhid
[ 0.667105] usbhid: USB HID core driver
[ 0.667814] vchiq: vchiq_init_state: slot_zero = bad80000, is_master = 0
[ 0.669180] [vc_sm_connected_init]: start
[ 0.678041] [vc_sm_connected_init]: end - returning 0
[ 0.678611] Initializing XFRM netlink socket
[ 0.678634] NET: Registered protocol family 17
[ 0.678723] Key type dns_resolver registered
[ 0.679255] Registering SWP/SWPB emulation handler
[ 0.679828] registered taskstats version 1
[ 0.685593] uart-pl011 3f201000.serial: cts_event_workaround enabled
[ 0.685666] 3f201000.serial: ttyAMA0 at MMIO 0x3f201000 (irq = 87, base_baud = 0) is a PL011 rev2
[ 0.687360] mmc-bcm2835 3f300000.mmc: mmc_debug:0 mmc_debug2:0
[ 0.687369] mmc-bcm2835 3f300000.mmc: DMA channel allocated
[ 0.742124] sdhost: log_buf @ bad07000 (fad07000)
[ 0.777908] mmc1: queuing unknown CIS tuple 0x80 (2 bytes)
[ 0.779479] mmc1: queuing unknown CIS tuple 0x80 (3 bytes)
[ 0.781049] mmc1: queuing unknown CIS tuple 0x80 (3 bytes)
[ 0.783840] mmc1: queuing unknown CIS tuple 0x80 (7 bytes)
[ 0.821525] mmc0: sdhost-bcm2835 loaded - DMA enabled (>1)
[ 0.822544] of_cfs_init
[ 0.822680] of_cfs_init: OK
[ 0.823207] Waiting for root device /dev/sda2...
[ 0.881718] Indeed it is in host mode hprt0 = 00021501
[ 0.949309] mmc0: host does not support reading read-only switch, assuming write-enable
[ 0.952145] mmc0: new high speed SDHC card at address 0002
[ 0.952674] mmcblk0: mmc0:0002 N/A 7.50 GiB
[ 0.954439] mmcblk0: p1 p2
[ 0.963054] mmc1: new high speed SDIO card at address 0001
[ 1.091545] usb 1-1: new high-speed USB device number 2 using dwc_otg
[ 1.091660] Indeed it is in host mode hprt0 = 00001101
[ 1.331765] usb 1-1: New USB device found, idVendor=0424, idProduct=9514
[ 1.331777] usb 1-1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
[ 1.332308] hub 1-1:1.0: USB hub found
[ 1.332384] hub 1-1:1.0: 5 ports detected
[ 1.651530] usb 1-1.1: new high-speed USB device number 3 using dwc_otg
[ 1.781737] usb 1-1.1: New USB device found, idVendor=0424, idProduct=ec00
[ 1.781748] usb 1-1.1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
[ 1.784246] smsc95xx v1.0.6
[ 1.874508] smsc95xx 1-1.1:1.0 eth0: register 'smsc95xx' at usb-3f980000.usb-1.1, smsc95xx USB 2.0 Ethernet, b8:27:eb:ce:cf:d8
[ 1.971532] usb 1-1.3: new high-speed USB device number 4 using dwc_otg
[ 2.101870] usb 1-1.3: New USB device found, idVendor=1a40, idProduct=0101
[ 2.101881] usb 1-1.3: New USB device strings: Mfr=0, Product=1, SerialNumber=0
[ 2.101889] usb 1-1.3: Product: USB 2.0 Hub
[ 2.102340] hub 1-1.3:1.0: USB hub found
[ 2.102428] hub 1-1.3:1.0: 4 ports detected
[ 2.201531] usb 1-1.4: new low-speed USB device number 5 using dwc_otg
[ 2.336528] usb 1-1.4: New USB device found, idVendor=0461, idProduct=4e66
[ 2.336539] usb 1-1.4: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[ 2.336548] usb 1-1.4: Product: HP USB Optical Mouse
[ 2.336556] usb 1-1.4: Manufacturer: PixArt
[ 2.341392] input: PixArt HP USB Optical Mouse as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4:1.0/0003:0461:4E66.0001/input/input0
[ 2.341723] hid-generic 0003:0461:4E66.0001: input,hidraw0: USB HID v1.11 Mouse [PixArt HP USB Optical Mouse] on usb-3f980000.usb-1.4/input0
[ 2.441532] usb 1-1.5: new low-speed USB device number 6 using dwc_otg
[ 2.743405] usb 1-1.5: New USB device found, idVendor=17ef, idProduct=602d
[ 2.743416] usb 1-1.5: New USB device strings: Mfr=1, Product=2, SerialNumber=0
[ 2.743424] usb 1-1.5: Product: Lenovo Black Silk USB Keyboard
[ 2.743432] usb 1-1.5: Manufacturer: Lenovo
[ 2.811427] input: Lenovo Lenovo Black Silk USB Keyboard as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.5/1-1.5:1.0/0003:17EF:602D.0002/input/input1
[ 2.871993] hid-generic 0003:17EF:602D.0002: input,hidraw1: USB HID v1.11 Keyboard [Lenovo Lenovo Black Silk USB Keyboard] on usb-3f980000.usb-1.5/input0
[ 3.010240] input: Lenovo Lenovo Black Silk USB Keyboard as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.5/1-1.5:1.1/0003:17EF:602D.0003/input/input2
[ 3.071679] hid-generic 0003:17EF:602D.0003: input,hidraw2: USB HID v1.11 Device [Lenovo Lenovo Black Silk USB Keyboard] on usb-3f980000.usb-1.5/input1
[ 16.066037] random: crng init done
[ 16.131538] usb 1-1.3.4: new high-speed USB device number 7 using dwc_otg
[ 16.322842] usb 1-1.3.4: New USB device found, idVendor=1058, idProduct=0a10
[ 16.322854] usb 1-1.3.4: New USB device strings: Mfr=1, Product=2, SerialNumber=5
[ 16.322863] usb 1-1.3.4: Product: USB to SATA bridge
[ 16.322871] usb 1-1.3.4: Manufacturer: JMicron
[ 16.322880] usb 1-1.3.4: SerialNumber: 1234567890123
[ 16.323813] usb-storage 1-1.3.4:1.0: USB Mass Storage device detected
[ 16.324167] scsi host0: usb-storage 1-1.3.4:1.0
[ 17.352197] scsi 0:0:0:0: Direct-Access WDC WD32 00AAKS-00B3A0 9122 PQ: 0 ANSI: 6
[ 17.353496] sd 0:0:0:0: [sda] 625142448 512-byte logical blocks: (320 GB/298 GiB)
[ 17.353927] sd 0:0:0:0: [sda] Write Protect is off
[ 17.353939] sd 0:0:0:0: [sda] Mode Sense: 47 00 10 08
[ 17.354366] sd 0:0:0:0: [sda] No Caching mode page found
[ 17.354538] sd 0:0:0:0: [sda] Assuming drive cache: write through
[ 17.364547] sda: sda1 sda2 sda3
[ 17.366854] sd 0:0:0:0: [sda] Attached SCSI disk
[ 17.533419] EXT4-fs (sda2): mounted filesystem with ordered data mode. Opts: (null)
[ 17.533483] VFS: Mounted root (ext4 filesystem) readonly on device 8:2.
[ 17.588323] devtmpfs: mounted
[ 17.591366] Freeing unused kernel memory: 1024K
[ 18.320199] systemd[1]: System time before build time, advancing clock.
[ 18.616909] NET: Registered protocol family 10
[ 18.618227] Segment Routing with IPv6
[ 18.638749] ip_tables: (C) 2000-2006 Netfilter Core Team
[ 18.731289] systemd[1]: systemd 232 running in system mode. (+PAM +AUDIT +SELINUX +IMA +APPARMOR +SMACK +SYSVINIT +UTMP +LIBCRYPTSETUP +GCRYPT +GNUTLS +ACL +XZ +LZ4 +SECCOMP +BLKID +ELFUTILS +KMOD +IDN)
[ 18.731916] systemd[1]: Detected architecture arm.
[ 18.738731] systemd[1]: Set hostname to <raspberrypi>.
[ 19.922840] systemd[1]: Listening on udev Control Socket.
[ 19.923429] systemd[1]: Listening on Journal Socket.
[ 19.923774] systemd[1]: Started Forward Password Requests to Wall Directory Watch.
[ 19.924596] systemd[1]: Set up automount Arbitrary Executable File Formats File System Automount Point.
[ 19.924797] systemd[1]: Listening on Syslog Socket.
[ 19.925042] systemd[1]: Listening on /dev/initctl Compatibility Named Pipe.
[ 19.925229] systemd[1]: Listening on fsck to fsckd communication Socket.
[ 20.689540] i2c /dev entries driver
[ 21.146991] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CPU DAI (null) not registered - will retry
[ 38.019083] EXT4-fs (sda2): re-mounted. Opts: (null)
[ 38.185471] systemd-journald[99]: Received request to flush runtime journal from PID 1
[ 38.478633] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CPU DAI (null) not registered - will retry
[ 38.487694] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CPU DAI (null) not registered - will retry
[ 38.595373] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CPU DAI (null) not registered - will retry
[ 38.671385] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CODEC DAI pcm512x-hifi not registered - will retry
[ 38.716388] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CODEC DAI pcm512x-hifi not registered - will retry
[ 38.726895] snd_bcm2835: module is from the staging directory, the quality is unknown, you have been warned.
[ 38.729700] bcm2835_alsa bcm2835_alsa: card created with 8 channels
[ 38.729980] snd-rpi-hifiberry-dacplus soc:sound: ASoC: CODEC DAI pcm512x-hifi not registered - will retry
[ 39.339606] snd-rpi-hifiberry-dacplus soc:sound: pcm512x-hifi <-> 3f203000.i2s mapping ok
[ 39.473959] brcmfmac: F1 signature read @0x18000000=0x1541a9a6
[ 39.479398] brcmfmac: brcmf_fw_map_chip_to_name: using brcm/brcmfmac43430-sdio.bin for chip 0x00a9a6(43430) rev 0x000001
[ 39.479660] usbcore: registered new interface driver brcmfmac
[ 39.764618] sd 0:0:0:0: Attached scsi generic sg0 type 0
[ 39.788100] brcmfmac: brcmf_c_preinit_dcmds: Firmware version = wl0: Oct 23 2017 03:55:53 version 7.45.98.38 (r674442 CY) FWID 01-e58d219f
[ 39.788903] brcmfmac: brcmf_c_preinit_dcmds: CLM version = API: 12.2 Data: 7.11.15 Compiler: 1.24.2 ClmImport: 1.24.1 Creation: 2014-05-26 10:53:55 Inc Data: 9.10.39 Inc Compiler: 1.29.4 Inc ClmImport: 1.36.3 Creation: 2017-10-23 03:47:14
[ 42.012733] uart-pl011 3f201000.serial: no DMA platform data
[ 43.779788] IPv6: ADDRCONF(NETDEV_UP): wlan0: link is not ready
[ 43.779816] brcmfmac: power management disabled
[ 44.283747] smsc95xx 1-1.1:1.0 eth0: hardware isn't capable of remote wakeup
[ 44.284159] IPv6: ADDRCONF(NETDEV_UP): eth0: link is not ready
[ 44.694401] Adding 102396k swap on /var/swap. Priority:-2 extents:2 across:126972k FS
[ 44.913786] IPv6: ADDRCONF(NETDEV_CHANGE): wlan0: link becomes ready
[ 46.569457] Bluetooth: Core ver 2.22
[ 46.569531] NET: Registered protocol family 31
[ 46.569537] Bluetooth: HCI device and connection manager initialized
[ 46.569558] Bluetooth: HCI socket layer initialized
[ 46.569570] Bluetooth: L2CAP socket layer initialized
[ 46.569603] Bluetooth: SCO socket layer initialized
[ 46.746448] Bluetooth: HCI UART driver ver 2.3
[ 46.746461] Bluetooth: HCI UART protocol H4 registered
[ 46.746467] Bluetooth: HCI UART protocol Three-wire (H5) registered
[ 46.746707] Bluetooth: HCI UART protocol Broadcom registered
[ 47.151737] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[ 47.151748] Bluetooth: BNEP filters: protocol multicast
[ 47.151768] Bluetooth: BNEP socket layer initialized
[ 47.299430] Bluetooth: RFCOMM TTY layer initialized
[ 47.299478] Bluetooth: RFCOMM socket layer initialized
[ 47.299508] Bluetooth: RFCOMM ver 1.11
[ 52.764775] fuse init (API version 7.26)
[ 337.344559] Adding 10485592k swap on /dev/sda3. Priority:-2 extents:1 across:10485592k FS

lsmod
Module Size Used by
iptable_filter 16384 0
fuse 106496 3
rfcomm 49152 6
cmac 16384 1
bnep 20480 2
hci_uart 36864 1
btbcm 16384 1 hci_uart
serdev 20480 1 hci_uart
bluetooth 368640 29 hci_uart,bnep,btbcm,rfcomm
ecdh_generic 28672 1 bluetooth
evdev 24576 6
sg 28672 0
brcmfmac 307200 0
brcmutil 16384 1 brcmfmac
cfg80211 573440 1 brcmfmac
snd_soc_pcm512x_i2c 16384 1
snd_soc_pcm512x 32768 1 snd_soc_pcm512x_i2c
rfkill 28672 6 bluetooth,cfg80211
snd_bcm2835 32768 0
i2c_bcm2835 16384 0
snd_soc_bcm2835_i2s 16384 2
clk_hifiberry_dacpro 16384 1
uio_pdrv_genirq 16384 0
uio 20480 1 uio_pdrv_genirq
fixed 16384 3
snd_soc_hifiberry_dacplus 16384 1
snd_soc_core 188416 3 snd_soc_pcm512x,snd_soc_hifiberry_dacplus,snd_soc_bcm2835_i2s
snd_compress 20480 1 snd_soc_core
snd_pcm_dmaengine 16384 1 snd_soc_core
snd_pcm 98304 6 snd_soc_pcm512x,snd_pcm_dmaengine,snd_soc_hifiberry_dacplus,snd_soc_bcm2835_i2s,snd_bcm2835,snd_soc_core
snd_timer 32768 1 snd_pcm
snd 69632 7 snd_compress,snd_timer,snd_bcm2835,snd_soc_core,snd_pcm
i2c_dev 16384 0
ip_tables 24576 1 iptable_filter
x_tables 32768 2 ip_tables,iptable_filter
ipv6 434176 24

# lsusb
Bus 001 Device 006: ID 17ef:602d Lenovo
Bus 001 Device 005: ID 0461:4e66 Primax Electronics, Ltd
Bus 001 Device 007: ID 1058:0a10 Western Digital Technologies, Inc.
Bus 001 Device 004: ID 1a40:0101 Terminus Technology Inc. Hub
Bus 001 Device 003: ID 0424:ec00 Standard Microsystems Corp. SMSC9512/9514 Fast Ethernet Adapter
Bus 001 Device 002: ID 0424:9514 Standard Microsystems Corp. SMC9514 Hub
Bus 001 Device 001: ID 1d6b:0002 Linux Foundation 2.0 root hub

ls -l /lib/modules/4.14.34-v7+/kernel/sound/soc/bcm/
合計 352
-rw-r--r-- 1 root root 7784 4月 21 07:54 snd-soc-adau1977-adc.ko
-rw-r--r-- 1 root root 12552 4月 21 07:54 snd-soc-allo-boss-dac.ko
-rw-r--r-- 1 root root 10816 4月 21 07:54 snd-soc-allo-digione.ko
-rw-r--r-- 1 root root 21328 4月 21 07:54 snd-soc-allo-piano-dac-plus.ko
-rw-r--r-- 1 root root 8188 4月 21 07:54 snd-soc-allo-piano-dac.ko
-rw-r--r-- 1 root root 13748 4月 21 07:54 snd-soc-audioinjector-octo-soundcard.ko
-rw-r--r-- 1 root root 10204 4月 21 07:54 snd-soc-audioinjector-pi-soundcard.ko
-rw-r--r-- 1 root root 15204 4月 21 07:54 snd-soc-bcm2835-i2s.ko
-rw-r--r-- 1 root root 16192 4月 21 07:54 snd-soc-digidac1-soundcard.ko
-rw-r--r-- 1 root root 8288 4月 21 07:54 snd-soc-dionaudio-loco-v2.ko
-rw-r--r-- 1 root root 8032 4月 21 07:54 snd-soc-dionaudio-loco.ko
-rw-r--r-- 1 root root 8724 4月 21 07:54 snd-soc-fe-pi-audio.ko
-rw-r--r-- 1 root root 9996 4月 21 07:54 snd-soc-googlevoicehat-codec.ko
-rw-r--r-- 1 root root 8336 4月 21 07:54 snd-soc-googlevoicehat-soundcard.ko
-rw-r--r-- 1 root root 7944 4月 21 07:54 snd-soc-hifiberry-amp.ko
-rw-r--r-- 1 root root 8128 4月 21 07:54 snd-soc-hifiberry-dac.ko
-rw-r--r-- 1 root root 11584 4月 21 07:54 snd-soc-hifiberry-dacplus.ko
-rw-r--r-- 1 root root 11116 4月 21 07:54 snd-soc-hifiberry-digi.ko
-rw-r--r-- 1 root root 10776 4月 21 07:54 snd-soc-iqaudio-dac.ko
-rw-r--r-- 1 root root 10672 4月 21 07:54 snd-soc-iqaudio-digi.ko
-rw-r--r-- 1 root root 8844 4月 21 07:54 snd-soc-justboom-dac.ko
-rw-r--r-- 1 root root 9344 4月 21 07:54 snd-soc-justboom-digi.ko
-rw-r--r-- 1 root root 34432 4月 21 07:54 snd-soc-pisound.ko
-rw-r--r-- 1 root root 23748 4月 21 07:54 snd-soc-rpi-cirrus.ko
-rw-r--r-- 1 root root 7788 4月 21 07:54 snd-soc-rpi-dac.ko

-rw-r--r-- 1 root root 8476 4月 21 07:54 snd-soc-rpi-proto.ko

ls -l /boot/overlays

合計 1176

-rwxr-xr-x 1 root root 79565 4月 21 07:54 README

-rwxr-xr-x 1 root root 1027 4月 21 07:54 adau1977-adc.dtbo

-rwxr-xr-x 1 root root 1587 4月 21 07:54 adau7002-simple.dtbo

-rwxr-xr-x 1 root root 2425 4月 21 07:54 ads1015.dtbo

-rwxr-xr-x 1 root root 2425 4月 21 07:54 ads1115.dtbo

-rwxr-xr-x 1 root root 2426 4月 21 07:54 ads7846.dtbo

-rwxr-xr-x 1 root root 1387 4月 21 07:54 akkordion-iqdacplus.dtbo

-rwxr-xr-x 1 root root 1473 4月 21 07:54 allo-boss-dac-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1208 4月 21 07:54 allo-digione.dtbo

-rwxr-xr-x 1 root root 1011 4月 21 07:54 allo-piano-dac-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1585 4月 21 07:54 allo-piano-dac-plus-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1454 4月 21 07:54 applepi-dac.dtbo

-rwxr-xr-x 1 root root 1668 4月 21 07:54 at86rf233.dtbo

-rwxr-xr-x 1 root root 2144 4月 21 07:54 audioinjector-addons.dtbo

-rwxr-xr-x 1 root root 787 4月 21 07:54 audioinjector-wm8731-audio.dtbo

-rwxr-xr-x 1 root root 575 4月 21 07:54 audremap.dtbo

-rwxr-xr-x 1 root root 449 4月 21 07:54 bmp085_i2c-sensor.dtbo

-rwxr-xr-x 1 root root 983 4月 21 07:54 dht11.dtbo

-rwxr-xr-x 1 root root 1027 4月 21 07:54 dionaudio-loco-v2.dtbo

-rwxr-xr-x 1 root root 663 4月 21 07:54 dionaudio-loco.dtbo

-rwxr-xr-x 1 root root 765 4月 21 07:54 dpi18.dtbo

-rwxr-xr-x 1 root root 789 4月 21 07:54 dpi24.dtbo

-rwxr-xr-x 1 root root 423 4月 21 07:54 dwc-otg.dtbo

-rwxr-xr-x 1 root root 856 4月 21 07:54 dwc2.dtbo

-rwxr-xr-x 1 root root 1279 4月 21 07:54 enc28j60-spi2.dtbo

-rwxr-xr-x 1 root root 1403 4月 21 07:54 enc28j60.dtbo

-rwxr-xr-x 1 root root 1562 4月 21 07:54 exc3000.dtbo

-rwxr-xr-x 1 root root 1932 4月 21 07:54 fe-pi-audio.dtbo

-rwxr-xr-x 1 root root 1437 4月 21 07:54 goodix.dtbo

-rwxr-xr-x 1 root root 1259 4月 21 07:54 googlevoicehat-soundcard.dtbo

-rwxr-xr-x 1 root root 1096 4月 21 07:54 gpio-ir-tx.dtbo

-rwxr-xr-x 1 root root 1212 4月 21 07:54 gpio-ir.dtbo

-rwxr-xr-x 1 root root 1373 4月 21 07:54 gpio-key.dtbo

-rwxr-xr-x 1 root root 901 4月 21 07:54 gpio-poweroff.dtbo

-rwxr-xr-x 1 root root 1250 4月 21 07:54 gpio-shutdown.dtbo

-rwxr-xr-x 1 root root 779 4月 21 07:54 hifiberry-amp.dtbo

-rwxr-xr-x 1 root root 655 4月 21 07:54 hifiberry-dac.dtbo

-rwxr-xr-x 1 root root 1693 4月 21 07:54 hifiberry-dacplus.dtbo

-rwxr-xr-x 1 root root 1125 4月 21 07:54 hifiberry-digi-pro.dtbo

-rwxr-xr-x 1 root root 959 4月 21 07:54 hifiberry-digi.dtbo

-rwxr-xr-x 1 root root 2468 4月 21 07:54 hy28a.dtbo

-rwxr-xr-x 1 root root 2939 4月 21 07:54 hy28b.dtbo

-rwxr-xr-x 1 root root 270 4月 21 07:54 i2c-bcm2708.dtbo

-rwxr-xr-x 1 root root 1035 4月 21 07:54 i2c-gpio.dtbo

-rwxr-xr-x 1 root root 2185 4月 21 07:54 i2c-mux.dtbo

-rwxr-xr-x 1 root root 644 4月 21 07:54 i2c-pwm-pca9685a.dtbo

-rwxr-xr-x 1 root root 4143 4月 21 07:54 i2c-rtc-gpio.dtbo

-rwxr-xr-x 1 root root 3765 4月 21 07:54 i2c-rtc.dtbo

-rwxr-xr-x 1 root root 4402 4月 21 07:54 i2c-sensor.dtbo

-rwxr-xr-x 1 root root 1182 4月 21 07:54 i2c0-bcm2708.dtbo

-rwxr-xr-x 1 root root 805 4月 21 07:54 i2c1-bcm2708.dtbo

-rwxr-xr-x 1 root root 343 4月 21 07:54 i2s-gpio28-31.dtbo

-rwxr-xr-x 1 root root 1272 4月 21 07:54 iqaudio-dac.dtbo

-rwxr-xr-x 1 root root 1511 4月 21 07:54 iqaudio-dacplus.dtbo

-rwxr-xr-x 1 root root 1326 4月 21 07:54 iqaudio-digi-wm8804-audio.dtbo

-rwxr-xr-x 1 root root 5212 4月 21 07:54 jedec-spi-nor.dtbo

-rwxr-xr-x 1 root root 1276 4月 21 07:54 justboom-dac.dtbo

-rwxr-xr-x 1 root root 955 4月 21 07:54 justboom-digi.dtbo

-rwxr-xr-x 1 root root 1348 4月 21 07:54 lirc-rpi.dtbo

-rwxr-xr-x 1 root root 1605 4月 21 07:54 mbed-dac.dtbo

-rwxr-xr-x 1 root root 1329 4月 21 07:54 mcp23017.dtbo

-rwxr-xr-x 1 root root 15229 4月 21 07:54 mcp23s17.dtbo

-rwxr-xr-x 1 root root 1833 4月 21 07:54 mcp2515-can0.dtbo

-rwxr-xr-x 1 root root 1833 4月 21 07:54 mcp2515-can1.dtbo

-rwxr-xr-x 1 root root 4237 4月 21 07:54 mcp3008.dtbo

-rwxr-xr-x 1 root root 4237 4月 21 07:54 mcp3202.dtbo

-rwxr-xr-x 1 root root 3438 4月 21 07:54 media-center.dtbo

-rwxr-xr-x 1 root root 720 4月 21 07:54 midi-uart0.dtbo

-rwxr-xr-x 1 root root 857 4月 21 07:54 midi-uart1.dtbo

-rwxr-xr-x 1 root root 1099 4月 21 07:54 mmc.dtbo

-rwxr-xr-x 1 root root 796 4月 21 07:54 mpu6050.dtbo

-rwxr-xr-x 1 root root 2850 4月 21 07:54 mz61581.dtbo

-rwxr-xr-x 1 root root 2356 4月 21 07:54 papirus.dtbo

-rwxr-xr-x 1 root root 569 4月 21 07:54 pi3-act-led.dtbo

-rwxr-xr-x 1 root root 818 4月 21 07:54 pi3-disable-bt.dtbo

-rwxr-xr-x 1 root root 265 4月 21 07:54 pi3-disable-wifi.dtbo

-rwxr-xr-x 1 root root 1446 4月 21 07:54 pi3-miniuart-bt.dtbo

-rwxr-xr-x 1 root root 2334 4月 21 07:54 pibell.dtbo

-rwxr-xr-x 1 root root 2713 4月 21 07:54 piscreen.dtbo

-rwxr-xr-x 1 root root 2617 4月 21 07:54 piscreen2r.dtbo

-rwxr-xr-x 1 root root 2454 4月 21 07:54 pisound.dtbo

-rwxr-xr-x 1 root root 1544 4月 21 07:54 pitft22.dtbo

-rwxr-xr-x 1 root root 2385 4月 21 07:54 pitft28-capacitive.dtbo

-rwxr-xr-x 1 root root 2802 4月 21 07:54 pitft28-resistive.dtbo

-rwxr-xr-x 1 root root 2802 4月 21 07:54 pitft35-resistive.dtbo

-rwxr-xr-x 1 root root 1145 4月 21 07:54 pps-gpio.dtbo

-rwxr-xr-x 1 root root 1057 4月 21 07:54 pwm-2chan.dtbo

-rwxr-xr-x 1 root root 1031 4月 21 07:54 pwm-ir-tx.dtbo

-rwxr-xr-x 1 root root 946 4月 21 07:54 pwm.dtbo

-rwxr-xr-x 1 root root 1315 4月 21 07:54 qca7000.dtbo

-rwxr-xr-x 1 root root 1922 4月 21 07:54 rotary-encoder.dtbo

-rwxr-xr-x 1 root root 489 4月 21 07:54 rpi-backlight.dtbo

-rwxr-xr-x 1 root root 3406 4月 21 07:54 rpi-cirrus-wm5102.dtbo

-rwxr-xr-x 1 root root 643 4月 21 07:54 rpi-dac.dtbo

-rwxr-xr-x 1 root root 2598 4月 21 07:54 rpi-display.dtbo

-rwxr-xr-x 1 root root 1018 4月 21 07:54 rpi-ft5406.dtbo

-rwxr-xr-x 1 root root 771 4月 21 07:54 rpi-proto.dtbo

-rwxr-xr-x 1 root root 893 4月 21 07:54 rpi-sense.dtbo

-rwxr-xr-x 1 root root 499 4月 21 07:54 rpi-tv.dtbo

-rwxr-xr-x 1 root root 1298 4月 21 07:54 rra-digidac1-wm8741-audio.dtbo

-rwxr-xr-x 1 root root 1174 4月 21 07:54 sc16is750-i2c.dtbo

-rwxr-xr-x 1 root root 1344 4月 21 07:54 sc16is752-i2c.dtbo

-rwxr-xr-x 1 root root 1875 4月 21 07:54 sc16is752-spi1.dtbo

-rwxr-xr-x 1 root root 846 4月 21 07:54 sdhost.dtbo

-rwxr-xr-x 1 root root 1729 4月 21 07:54 sdio-1bit.dtbo

-rwxr-xr-x 1 root root 1797 4月 21 07:54 sdio.dtbo

-rwxr-xr-x 1 root root 699 4月 21 07:54 sdtweak.dtbo

-rwxr-xr-x 1 root root 376 4月 21 07:54 smi-dev.dtbo

-rwxr-xr-x 1 root root 1508 4月 21 07:54 smi-nand.dtbo

-rwxr-xr-x 1 root root 981 4月 21 07:54 smi.dtbo

-rwxr-xr-x 1 root root 666 4月 21 07:54 spi-gpio35-39.dtbo

-rwxr-xr-x 1 root root 635 4月 21 07:54 spi-rtc.dtbo

-rwxr-xr-x 1 root root 919 4月 21 07:54 spi0-cs.dtbo

-rwxr-xr-x 1 root root 492 4月 21 07:54 spi0-hw-cs.dtbo

-rwxr-xr-x 1 root root 1547 4月 21 07:54 spi1-1cs.dtbo

-rwxr-xr-x 1 root root 1920 4月 21 07:54 spi1-2cs.dtbo

-rwxr-xr-x 1 root root 2293 4月 21 07:54 spi1-3cs.dtbo

-rwxr-xr-x 1 root root 1547 4月 21 07:54 spi2-1cs.dtbo

-rwxr-xr-x 1 root root 1920 4月 21 07:54 spi2-2cs.dtbo

-rwxr-xr-x 1 root root 2293 4月 21 07:54 spi2-3cs.dtbo

-rwxr-xr-x 1 root root 1968 4月 21 07:54 superaudioboard.dtbo

-rwxr-xr-x 1 root root 35594 4月 21 07:54 sx150x.dtbo

-rwxr-xr-x 1 root root 4878 4月 21 07:54 tinylcd35.dtbo

-rwxr-xr-x 1 root root 928 4月 21 07:54 uart0.dtbo

-rwxr-xr-x 1 root root 980 4月 21 07:54 uart1.dtbo

-rwxr-xr-x 1 root root 715 4月 21 07:54 upstream-aux-interrupt.dtbo

-rwxr-xr-x 1 root root 3215 4月 21 07:54 upstream.dtbo

-rwxr-xr-x 1 root root 1412 4月 21 07:54 vc4-fkms-v3d.dtbo

-rwxr-xr-x 1 root root 2367 4月 21 07:54 vc4-kms-v3d.dtbo

-rwxr-xr-x 1 root root 758 4月 21 07:54 vga666.dtbo

-rwxr-xr-x 1 root root 1251 4月 21 07:54 w1-gpio-pullup.dtbo

-rwxr-xr-x 1 root root 1116 4月 21 07:54 w1-gpio.dtbo

-rwxr-xr-x 1 root root 1080 4月 21 07:54 wittypi.dtbo

2017年8月2日水曜日

raspberry pi 3 で　hostapd + dnsmasq で　wifi アクセスポイントをつくる

wifi access point をつくる

なイメージです。

英語の
https://frillip.com/using-your-raspberry-pi-3-as-a-wifi-access-point-with-hostapd/
のとおり

最終のスクリプトは
./wifi-accessPoint.bat
sh -c "echo 1 > /proc/sys/net/ipv4/ip_forward"

iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
iptables -A FORWARD -i eth0 -o wlan0 -m state --state RELATED,ESTABLISHED -j ACCEPT
iptables -A FORWARD -i wlan0 -o eth0 -j ACCEPT

service hostapd start
service dnsmasq start

必要な道具を用意します
aptitude install hostapd dnsmasq

/etc/dhcpcd.conf
hostname
clientid
persistent
option rapid_commit
option domain_name_servers, domain_name, domain_search, host_name
option classless_static_routes
option ntp_servers
require dhcp_server_identifier
slaac private
nohook lookup-hostname
denyinterfaces wlan0

ヘリポートにアドレスをふります
/etc/network/interfaces

source-directory /etc/network/interfaces.d
auto lo
iface lo inet loopback
iface eth0 inet manual
allow-hotplug wlan0
iface wlan0 inet static
address 172.24.1.1
netmask 255.255.255.0
network 172.24.1.0
broadcast 172.24.1.255

ヘリコプターがつける準備です
/etc/hostapd/hostapd.conf

interface=wlan0
driver=nl80211
ssid=Pi3-AP
hw_mode=g
channel=6
ieee80211n=1
wmm_enabled=1
ht_capab=[HT40][SHORT-GI-20][DSSS_CCK-40]
macaddr_acl=0
auth_algs=1
ignore_broadcast_ssid=0
wpa=2
wpa_key_mgmt=WPA-PSK
wpa_passphrase=1122334455

rsn_pairwise=CCMP

切符がないと　新幹線にはのれませんので
/etc/dnsmasq.conf
interface=wlan0 # Use interface wlan0
listen-address=172.24.1.1 # Explicitly specify the address to listen on
bind-interfaces # Bind to the interface to make sure we aren't sending things elsewhere
server=8.8.8.8 # Forward DNS requests to Google DNS
domain-needed # Don't forward short names
bogus-priv
dhcp-range=172.24.1.50,172.24.1.55,12h

これにて　
wifi いう電波に乗って　ヘリポートにおりたち（hostapdの役割）

dnsmasqから　切符をもらい

iptables によって新幹線にいけます

感謝です
日本語のサイトはいろいろ試しましたが駄目でした。
isc-dhcp サーバーは危なすぎます

2017年7月27日木曜日

raspbianでハイレゾを演奏する（volumio からでないよー）

a)　swapを大きくする編
http://inaba.hatenablog.com/entry/2016/12/13/023251を参考にして

SWAPが少なすぎるし　かつ　マイクロSDメモリでは　これがこわれちゃうので
（マイクロSDメモリには　システムがはいってる）
SWAPを本体から　分離する

cat /etc/rc.local

.
_IP=$(hostname -I) || true
if [ "$_IP" ]; then
printf "My IP address is %s\n" "$_IP"
fi
swapon /dev/sda2
service dphys-swapfile stop
exit 0

b)ラスビアンで　ハイレゾ編

まず
# aptitude update
# aptitude upgrade
# rpi-update
をします

$ ls -l /lib/modules/4.9.37-v7+/kernel/sound/soc/bcm/
total 356
-rw-r--r-- 1 root root 7684 Jul 20 16:02 snd-soc-adau1977-adc.ko
-rw-r--r-- 1 root root 12528 Jul 20 16:02 snd-soc-allo-boss-dac.ko
-rw-r--r-- 1 root root 10720 Jul 20 16:02 snd-soc-allo-digione.ko
-rw-r--r-- 1 root root 8592 Jul 20 16:02 snd-soc-allo-piano-dac.ko
-rw-r--r-- 1 root root 19396 Jul 20 16:02 snd-soc-allo-piano-dac-plus.ko
-rw-r--r-- 1 root root 13248 Jul 20 16:02 snd-soc-audioinjector-octo-soundcard.ko
-rw-r--r-- 1 root root 10104 Jul 20 16:02 snd-soc-audioinjector-pi-soundcard.ko
-rw-r--r-- 1 root root 13468 Jul 20 16:02 snd-soc-bcm2835-i2s.ko
-rw-r--r-- 1 root root 16092 Jul 20 16:02 snd-soc-digidac1-soundcard.ko
-rw-r--r-- 1 root root 7872 Jul 20 16:02 snd-soc-dionaudio-loco.ko
-rw-r--r-- 1 root root 8704 Jul 20 16:02 snd-soc-dionaudio-loco-v2.ko
-rw-r--r-- 1 root root 8628 Jul 20 16:02 snd-soc-fe-pi-audio.ko
-rw-r--r-- 1 root root 9896 Jul 20 16:02 snd-soc-googlevoicehat-codec.ko
-rw-r--r-- 1 root root 8240 Jul 20 16:02 snd-soc-googlevoicehat-soundcard.ko
-rw-r--r-- 1 root root 7848 Jul 20 16:02 snd-soc-hifiberry-amp.ko
-rw-r--r-- 1 root root 8028 Jul 20 16:02 snd-soc-hifiberry-dac.ko
-rw-r--r-- 1 root root 11424 Jul 20 16:02 snd-soc-hifiberry-dacplus.ko
-rw-r--r-- 1 root root 11020 Jul 20 16:02 snd-soc-hifiberry-digi.ko
-rw-r--r-- 1 root root 11180 Jul 20 16:02 snd-soc-iqaudio-dac.ko
-rw-r--r-- 1 root root 10508 Jul 20 16:02 snd-soc-iqaudio-digi.ko
-rw-r--r-- 1 root root 9204 Jul 20 16:02 snd-soc-justboom-dac.ko
-rw-r--r-- 1 root root 9180 Jul 20 16:02 snd-soc-justboom-digi.ko
-rw-r--r-- 1 root root 26244 Jul 20 16:02 snd-soc-pisound.ko
-rw-r--r-- 1 root root 9528 Jul 20 16:02 snd-soc-raspidac3.ko
-rw-r--r-- 1 root root 23584 Jul 20 16:02 snd-soc-rpi-cirrus.ko
-rw-r--r-- 1 root root 7628 Jul 20 16:02 snd-soc-rpi-dac.ko
-rw-r--r-- 1 root root 8312 Jul 20 16:02 snd-soc-rpi-proto.ko

なので

/etc/modules
----------------------------------
i2c-dev
snd-soc-hifiberry-dacplus

ls -l /boot/overlays

total 269

-rwxr-xr-x 1 root root 1027 Jul 20 16:02 adau1977-adc.dtbo

-rwxr-xr-x 1 root root 1587 Jul 20 16:02 adau7002-simple.dtbo

-rwxr-xr-x 1 root root 2425 Jul 20 16:02 ads1015.dtbo

-rwxr-xr-x 1 root root 2425 Jul 20 16:02 ads1115.dtbo

-rwxr-xr-x 1 root root 2426 Jul 20 16:02 ads7846.dtbo

-rwxr-xr-x 1 root root 1387 Jul 20 16:02 akkordion-iqdacplus.dtbo

-rwxr-xr-x 1 root root 1473 Jul 20 16:02 allo-boss-dac-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1208 Jul 20 16:02 allo-digione.dtbo

-rwxr-xr-x 1 root root 1011 Jul 20 16:02 allo-piano-dac-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1585 Jul 20 16:02 allo-piano-dac-plus-pcm512x-audio.dtbo

-rwxr-xr-x 1 root root 1668 Jul 20 16:02 at86rf233.dtbo

-rwxr-xr-x 1 root root 1972 Jul 20 16:02 audioinjector-addons.dtbo

-rwxr-xr-x 1 root root 787 Jul 20 16:02 audioinjector-wm8731-audio.dtbo

-rwxr-xr-x 1 root root 575 Jul 20 16:02 audremap.dtbo

-rwxr-xr-x 1 root root 449 Jul 20 16:02 bmp085_i2c-sensor.dtbo

-rwxr-xr-x 1 root root 983 Jul 20 16:02 dht11.dtbo

-rwxr-xr-x 1 root root 663 Jul 20 16:02 dionaudio-loco.dtbo

-rwxr-xr-x 1 root root 1027 Jul 20 16:02 dionaudio-loco-v2.dtbo

-rwxr-xr-x 1 root root 765 Jul 20 16:02 dpi18.dtbo

-rwxr-xr-x 1 root root 789 Jul 20 16:02 dpi24.dtbo

-rwxr-xr-x 1 root root 852 Jul 20 16:02 dwc2.dtbo

-rwxr-xr-x 1 root root 423 Jul 20 16:02 dwc-otg.dtbo

-rwxr-xr-x 1 root root 1403 Jul 20 16:02 enc28j60.dtbo

-rwxr-xr-x 1 root root 1279 Jul 20 16:02 enc28j60-spi2.dtbo

-rwxr-xr-x 1 root root 1932 Jul 20 16:02 fe-pi-audio.dtbo

-rwxr-xr-x 1 root root 1437 Jul 20 16:02 goodix.dtbo

-rwxr-xr-x 1 root root 1259 Jul 20 16:02 googlevoicehat-soundcard.dtbo

-rwxr-xr-x 1 root root 1036 Jul 20 16:02 gpio-ir.dtbo

-rwxr-xr-x 1 root root 901 Jul 20 16:02 gpio-poweroff.dtbo

-rwxr-xr-x 1 root root 1250 Jul 20 16:02 gpio-shutdown.dtbo

-rwxr-xr-x 1 root root 779 Jul 20 16:02 hifiberry-amp.dtbo

-rwxr-xr-x 1 root root 655 Jul 20 16:02 hifiberry-dac.dtbo

-rwxr-xr-x 1 root root 1693 Jul 20 16:02 hifiberry-dacplus.dtbo

-rwxr-xr-x 1 root root 959 Jul 20 16:02 hifiberry-digi.dtbo

-rwxr-xr-x 1 root root 1125 Jul 20 16:02 hifiberry-digi-pro.dtbo

-rwxr-xr-x 1 root root 2468 Jul 20 16:02 hy28a.dtbo

-rwxr-xr-x 1 root root 2939 Jul 20 16:02 hy28b.dtbo

-rwxr-xr-x 1 root root 1182 Jul 20 16:02 i2c0-bcm2708.dtbo

-rwxr-xr-x 1 root root 854 Jul 20 16:02 i2c1-bcm2708.dtbo

-rwxr-xr-x 1 root root 270 Jul 20 16:02 i2c-bcm2708.dtbo

-rwxr-xr-x 1 root root 991 Jul 20 16:02 i2c-gpio.dtbo

-rwxr-xr-x 1 root root 2185 Jul 20 16:02 i2c-mux.dtbo

-rwxr-xr-x 1 root root 644 Jul 20 16:02 i2c-pwm-pca9685a.dtbo

-rwxr-xr-x 1 root root 3442 Jul 20 16:02 i2c-rtc.dtbo

-rwxr-xr-x 1 root root 4143 Jul 20 16:02 i2c-rtc-gpio.dtbo

-rwxr-xr-x 1 root root 2864 Jul 20 16:02 i2c-sensor.dtbo

-rwxr-xr-x 1 root root 343 Jul 20 16:02 i2s-gpio28-31.dtbo

-rwxr-xr-x 1 root root 1272 Jul 20 16:02 iqaudio-dac.dtbo

-rwxr-xr-x 1 root root 1511 Jul 20 16:02 iqaudio-dacplus.dtbo

-rwxr-xr-x 1 root root 1326 Jul 20 16:02 iqaudio-digi-wm8804-audio.dtbo

-rwxr-xr-x 1 root root 1276 Jul 20 16:02 justboom-dac.dtbo

-rwxr-xr-x 1 root root 955 Jul 20 16:02 justboom-digi.dtbo

-rwxr-xr-x 1 root root 1348 Jul 20 16:02 lirc-rpi.dtbo

-rwxr-xr-x 1 root root 1329 Jul 20 16:02 mcp23017.dtbo

-rwxr-xr-x 1 root root 15229 Jul 20 16:02 mcp23s17.dtbo

-rwxr-xr-x 1 root root 1833 Jul 20 16:02 mcp2515-can0.dtbo

-rwxr-xr-x 1 root root 1833 Jul 20 16:02 mcp2515-can1.dtbo

-rwxr-xr-x 1 root root 4237 Jul 20 16:02 mcp3008.dtbo

-rwxr-xr-x 1 root root 720 Jul 20 16:02 midi-uart0.dtbo

-rwxr-xr-x 1 root root 857 Jul 20 16:02 midi-uart1.dtbo

-rwxr-xr-x 1 root root 1099 Jul 20 16:02 mmc.dtbo

-rwxr-xr-x 1 root root 796 Jul 20 16:02 mpu6050.dtbo

-rwxr-xr-x 1 root root 2850 Jul 20 16:02 mz61581.dtbo

-rwxr-xr-x 1 root root 569 Jul 20 16:02 pi3-act-led.dtbo

-rwxr-xr-x 1 root root 818 Jul 20 16:02 pi3-disable-bt.dtbo

-rwxr-xr-x 1 root root 265 Jul 20 16:02 pi3-disable-wifi.dtbo

-rwxr-xr-x 1 root root 1105 Jul 20 16:02 pi3-miniuart-bt.dtbo

-rwxr-xr-x 1 root root 2617 Jul 20 16:02 piscreen2r.dtbo

-rwxr-xr-x 1 root root 2713 Jul 20 16:02 piscreen.dtbo

-rwxr-xr-x 1 root root 2454 Jul 20 16:02 pisound.dtbo

-rwxr-xr-x 1 root root 1544 Jul 20 16:02 pitft22.dtbo

-rwxr-xr-x 1 root root 2385 Jul 20 16:02 pitft28-capacitive.dtbo

-rwxr-xr-x 1 root root 2802 Jul 20 16:02 pitft28-resistive.dtbo

-rwxr-xr-x 1 root root 2802 Jul 20 16:02 pitft35-resistive.dtbo

-rwxr-xr-x 1 root root 1043 Jul 20 16:02 pps-gpio.dtbo

-rwxr-xr-x 1 root root 1057 Jul 20 16:02 pwm-2chan.dtbo

-rwxr-xr-x 1 root root 946 Jul 20 16:02 pwm.dtbo

-rwxr-xr-x 1 root root 1315 Jul 20 16:02 qca7000.dtbo

-rwxr-xr-x 1 root root 1301 Jul 20 16:02 raspidac3.dtbo

-rwxr-xr-x 1 root root 66511 Jul 20 16:02 README

-rwxr-xr-x 1 root root 1275 Jul 20 16:02 rotary-encoder.dtbo

-rwxr-xr-x 1 root root 489 Jul 20 16:02 rpi-backlight.dtbo

-rwxr-xr-x 1 root root 3406 Jul 20 16:02 rpi-cirrus-wm5102.dtbo

-rwxr-xr-x 1 root root 643 Jul 20 16:02 rpi-dac.dtbo

-rwxr-xr-x 1 root root 2524 Jul 20 16:02 rpi-display.dtbo

-rwxr-xr-x 1 root root 462 Jul 20 16:02 rpi-ft5406.dtbo

-rwxr-xr-x 1 root root 771 Jul 20 16:02 rpi-proto.dtbo

-rwxr-xr-x 1 root root 893 Jul 20 16:02 rpi-sense.dtbo

-rwxr-xr-x 1 root root 499 Jul 20 16:02 rpi-tv.dtbo

-rwxr-xr-x 1 root root 1298 Jul 20 16:02 rra-digidac1-wm8741-audio.dtbo

-rwxr-xr-x 1 root root 1174 Jul 20 16:02 sc16is750-i2c.dtbo

-rwxr-xr-x 1 root root 1875 Jul 20 16:02 sc16is752-spi1.dtbo

-rwxr-xr-x 1 root root 846 Jul 20 16:02 sdhost.dtbo

-rwxr-xr-x 1 root root 1078 Jul 20 16:02 sdio-1bit.dtbo

-rwxr-xr-x 1 root root 1116 Jul 20 16:02 sdio.dtbo

-rwxr-xr-x 1 root root 699 Jul 20 16:02 sdtweak.dtbo

-rwxr-xr-x 1 root root 376 Jul 20 16:02 smi-dev.dtbo

-rwxr-xr-x 1 root root 981 Jul 20 16:02 smi.dtbo

-rwxr-xr-x 1 root root 1508 Jul 20 16:02 smi-nand.dtbo

-rwxr-xr-x 1 root root 919 Jul 20 16:02 spi0-cs.dtbo

-rwxr-xr-x 1 root root 492 Jul 20 16:02 spi0-hw-cs.dtbo

-rwxr-xr-x 1 root root 1547 Jul 20 16:02 spi1-1cs.dtbo

-rwxr-xr-x 1 root root 1920 Jul 20 16:02 spi1-2cs.dtbo

-rwxr-xr-x 1 root root 2293 Jul 20 16:02 spi1-3cs.dtbo

-rwxr-xr-x 1 root root 1547 Jul 20 16:02 spi2-1cs.dtbo

-rwxr-xr-x 1 root root 1920 Jul 20 16:02 spi2-2cs.dtbo

-rwxr-xr-x 1 root root 2293 Jul 20 16:02 spi2-3cs.dtbo

-rwxr-xr-x 1 root root 666 Jul 20 16:02 spi-gpio35-39.dtbo

-rwxr-xr-x 1 root root 635 Jul 20 16:02 spi-rtc.dtbo

-rwxr-xr-x 1 root root 4878 Jul 20 16:02 tinylcd35.dtbo

-rwxr-xr-x 1 root root 980 Jul 20 16:02 uart1.dtbo

-rwxr-xr-x 1 root root 1412 Jul 20 16:02 vc4-fkms-v3d.dtbo

-rwxr-xr-x 1 root root 3108 Jul 20 16:02 vc4-kms-v3d.dtbo

-rwxr-xr-x 1 root root 758 Jul 20 16:02 vga666.dtbo

-rwxr-xr-x 1 root root 1116 Jul 20 16:02 w1-gpio.dtbo

-rwxr-xr-x 1 root root 1251 Jul 20 16:02 w1-gpio-pullup.dtbo

-rwxr-xr-x 1 root root 1080 Jul 20 16:02 wittypi.dtbo

なので

/boot/config.txt
------------------------------------------
dtoverlay=hifiberry-dacplus
dtparam=audio=on

●あとはi2s-DACを常用にするために

　メニューからPreferences > Audio Device Settingsを選びます。

　デフォルトではSound card の欄にはbcm2835 ALSA(Alsa mixer)しか出ていませんが、HypaerberryなんたらDAC(Alsa mixer)が選べます。

　Hypaerberryなんたら(Alsa mixer)を選び、Select Contorolsをクリックすると、Hypaerberryなんたらの機能が出るので、Analogueにチェックしました。
DSP Proguramをチェックすると、内部のフィルタなどの制御ができます。

　この設定をデフォルトにするため、Make Defaultをクリックします。

　OKを押します。

　これ以降、HDMIではなくi2s-DACボードから音が出ます。

１）日本語環境　

素描だけ

pi　の　パスワードは　raspberry
sudo su で　root権限になれる

aptitude search ipa | grep gothic　ー>fonts-ipafont-gothic

aptitude install fcitx-mozc im-config zenity

dpkg-revonfigure locales

dpkg-revonfigure tzdata

nano /etc/defaults/keyboard

２）wifi access point をつくる

ただ　英語の

https://frillip.com/using-your-raspberry-pi-3-as-a-wifi-access-point-with-hostapd/

のとおり

最終のスクリプトは

./wifi-accessPoint.bat
sh -c "echo 1 > /proc/sys/net/ipv4/ip_forward"

iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
iptables -A FORWARD -i eth0 -o wlan0 -m state --state RELATED,ESTABLISHED -j ACCEPT
iptables -A FORWARD -i wlan0 -o eth0 -j ACCEPT

service hostapd start
service dnsmasq start

aptitude install hostapd dnsmasq

/etc/dhcpcd.conf

hostname

clientid

persistent

option rapid_commit

option domain_name_servers, domain_name, domain_search, host_name
option classless_static_routes
option ntp_servers

require dhcp_server_identifier

slaac private

nohook lookup-hostname

denyinterfaces wlan0

/etc/network/interfaces

source-directory /etc/network/interfaces.d

auto lo

iface lo inet loopback

iface eth0 inet manual

allow-hotplug wlan0

iface wlan0 inet static

address 172.24.1.1

netmask 255.255.255.0

network 172.24.1.0

broadcast 172.24.1.255

/etc/dnsmasq.conf

interface=wlan0 # Use interface wlan0

listen-address=172.24.1.1 # Explicitly specify the address to listen on

bind-interfaces # Bind to the interface to make sure we aren't sending things elsewhere

server=8.8.8.8 # Forward DNS requests to Google DNS

domain-needed # Don't forward short names

bogus-priv

dhcp-range=172.24.1.50,172.24.1.55,12h

３）NGINX

nginxの　change ｒｏｏｔは　ー＞　 /var/www/html/

/etc/nginx/nginx.conf
user www-data;
worker_processes 4;
pid /run/nginx.pid;
events {
worker_connections 768;
}
http {
sendfile on;
tcp_nopush on;
tcp_nodelay on;
keepalive_timeout 65;
types_hash_max_size 2048;
include /etc/nginx/mime.types;
default_type application/octet-stream;
auth_basic "Restricted";
auth_basic_user_file /usr/share/nginx/.htpasswd;
ssl_protocols TLSv1 TLSv1.1 TLSv1.2; # Dropping SSLv3, ref: POODLE
ssl_prefer_server_ciphers on;
access_log /var/log/nginx/access.log;
error_log /var/log/nginx/error.log;
gzip on;
gzip_disable "msie6";
include /etc/nginx/conf.d/*.conf;
include /etc/nginx/sites-enabled/*;

}

./comment-out.bat /var/www/html/test/pre.bat

for x in ` ls *.mp4 `

echo "<a href=$x > $x </a> </p> </p>"

done

登録: 投稿 (Atom)
